Multi Color sorter

Demo Image

Multi Color sorter

Features

Intelligent image processing technology using high resolution HD color cameras
Precise image scanning with 16200 pixels lens.
Highly integrated realtime automated (IOT) technology
Special design for sorting color and shape to ensure accuracy.
Self-diagnosis and self-tuning technology for easy serviceability
Effortless customisation of acceptance and rejection
Easy interface with large touch screen
Electro-magnetic ejector for accurate flow of air
Uniform flow feeder for uninterrupted inputs
High brightness LED & amp; Low temperature rise longer service life
Low maintenance and less power consumption

Multi Color sorter Specification:

Technical Specification
Enquiry Now

Models	Channels	Capacity(T/H)	Voltage (V)	Power(KVA)	Compressor(Hp)	Air Pressure(Bar)	Weight(Kg)	Dimension(LxWxH in mm)
Aura C3	240	2.0 - 3.75	220V/50HZ	1.8	20	0.25-6	840	1704 x 1725 x 1917
Aura C4	320	3.5 - 6.0	220V/50HZ	2	25	0.25-6	1030	2094 x 1725 x 1917
Aura C5	400	4.5 - 7.5	220V/50HZ	3	30	0.25-6	1220	2484 x 1725 x 1917
Aura C6	480	5.0 - 8.5	220V/50HZ	3.5	35	0.25-6	1350	2874 x 1725 x 1917
Aura C7	560	6.0 - 10.0	220V/50HZ	4	40	0.25-6	1510	3264 x 1725 x 1917
